UNIVERSITI TEKNOLOGI MARA

BQS601 – MEASUREMENT OF CONSTRUCTION WORKS V

ASSIGNMENT NO: 1

TOPIC: SURFACE WATER DRAINAGE – OPEN DRAIN
LECTURER: MOHAMMAD NASHARUDINE SHUIB

NO. | NAME | STUDENT ID

1. KAMARULAIMAN BIN M RAYMI – 2018223944

2. NORAZIEYZAH BINTI ABDULLAH – 2018250846

3. NURARINA AMNI BINTI MOHD AZIZI – 2018249062

4. NURFATINI BINTI TAJUDDIN – 2018297712

PROGRAM: UKUR BAHAN
FACULTY: SENIBINA, PERANCANGAN DAN UKUR
UNIVERSITI TEKNOLOGI MARA

TAKING-OFF PAPER

PROJECT: PROPOSED CONSTRUCTION OF DEWAN SERBANGUNA AT LOT PT103, PELABUHAN KLANG, SELANGOR
DRWG. NO: PUB/QSM601/QSB621/JUL2017/1 DATE: 8/11/…

Item Description – Taking-off List:

1. Excavate trench to receive surface water drains, etc.

2. Extra for excavation trench in rock

3. Disposal of water

4. Concrete blinding

5. Concrete bed

6. 225mm thick brick wall

7. 20mm thick plastering to drain wall

8. 600 x 900 x 50mm thick precast concrete slab cover

9. Graded filter & UPVC Weepholes

10. 375 x 450 x 200mm thick precast concrete block drain

11. Connection to existing main drain

12. Testing

Direct Billing Paper – Element: Surface Water Drainage:

• Excavate trench to receive surface water drains (m³)
• Extra over excavate in rock (m³)
• Allow for keeping surface & excavations free of water (Item)
• 900mm wide x 50mm thick lean concrete (m)
• Plain in-situ concrete bed (m)
• 225mm thick brick wall (m²)
• 20mm thick cement & sand plaster (m²)
• Precast concrete block drains and slab covers (m)
• Graded filter (No.)
• Connection to existing drain (Item)
  Testing (Item)

Further Items on Next Page: Continued bill of quantities for precast drains, filters, slab covers, connections and testing.
